Specifications |
ENGINE AND TRANSMISSION
Displacement : 149cc
Max Power : 9.7 kW (13.1PS) / 8000 rpm
Bore : 57.3mm
Valves Per Cylinder : 2-valve
Fuel Delivery System : Fuel injection
Transmission Type : Constant mesh, 5-speed
Cylinders : Single Cylinder
Maximum Torque : 12.8 N.m (1.3 kg f.m) / 6000 rpm)
Stroke : 57.9mm
Compression Ratio : 9.5:1
No. of Gears : 5
Clutch : Wet, multiple disc
Brakes, Wheels & Suspension
Front Brake Type : Disc
Front Tyre Size : 100/80-17M/C (52P)NYLOGRIP ZAPPER-FX1
Tyre Type : Tubless
Rear Suspension : Monocross
Rear Brake Type : Drum
Rear Tyre Size : 140/60-R17M/C (63P)revz-Y
Front Suspension : Telescopic fork
DIMENSIONS AND CHASSIS
Kerb Weight : 133 kg
Overall Width : 770 cm
Wheelbase : 1,330 mm
Seat Height : 790 mm
Overall Length : 2060 cm
Overall Height : 1050 cm
Ground Clearance : 160 mm
Chassis Type : Diamond
OTHER INFORMATION
Fuel Tank Capacity : 12 L
Start Type : Electric Starter
Headlight Type : Headlight
Low Fuel Indicator : Equipped
Battery : 12V, 4.0AH (10H), Sealed type
Turn Signal : 12V, 10W x 2
|
