Specifications |
Engine & Transmission
Displacement : 113 CC
Maximum Torque : 8.1Nm (0.8kgf-m)/5000rpm
Valves Per Cylinder : 2-valve
Ignition : CDI (Capacitor Discharge Ignition)
Max Power : 7.1PS/7,500 rpm
Stroke : 4-stroke
Fuel Delivery System : Digital
Cooling System : Air-cooled
Brakes, Wheels & Suspension :
Front Brake Type : Hydraulic single disc brake
Rear Brake Size : 170mm
Rear Tyre Size : 90/100-10 53J
Front Suspension : Telescopic Fork
Rear Brake Type : Mechanical leading trailing drum brake
Front Tyre Size : 90/100-10 53J
Tyre Type : Tubeless
Rear Suspension : Unit swing
Dimensions & Chassis
Kerb Weight : 103 kg
Overall Width : 700 mm
Wheelbase : 1,270 mm
Seat Height : 775 mm
Overall Length : 1,820 mm
Overall Height : 1,115 mm
Ground Clearance : 130 mm
Other Information
Fuel Tank Capacity : 5.2 L
Start Type : Electric start & Kick start
Brake/Tail Light : 12V,21/5W x 1
Speedometer : Digital
Headlight Type : 12V,35/35Wx1
Turn Signal : 12V, 10W x 2 (Front & Rear)
|
