Specifications |
ENGINE AND TRANSMISSION
Displacement: 125 cc
Max Power: 6.0kW(8.2PS)/6500r/min
Maximum Torque: 9.7N.m(1.0kgf.m)/5000r/min Bore: 52.4 mm
Stroke: 57.9mm
Compression Ratio: 10.2:1
Fuel Delivery System: Fuel injection Ignition TCI(Transistor Controlled Ignition)
Cooling System: Air Cooled
Transmission Type: V-belt automatic
BRAKES, WHEELS AND SUSPENSION
Front Brake Type: Disc
Rear Brake Type: Drum
Front Tyre Size: 90/90-12 Tubeless
Rear Tyre Size: 110/90-10
Tyre Type: Tubeless
Front Suspension: Telescopic fork
Rear Suspension: Unit Swing
DIMENSIONS AND CHASSIS
Kerb Weight: 99kg
Overall Length: 1920 mm
Overall Width: 685mm
Overall Height: 1150 mm
Wheelbase: 1280 mm
Ground Clearance: 145mm
Seat Height: 780 mm
OTHER INFORMATION
Fuel Tank Capacity: 5.2 L
Start Type: Electric starter and kick starter
Battery: Maintenance free - 12V,5.0 Ah
Headlight Type: 12V,35/35W x 1
Brake/Tail Light: 12V,21/5W x 1
|
