Specifications |
ENGINE AND PERFORMANCE
Engine Type: Liquid-cooled, 4-stroke, SOHC, 4-valve
Displacement : 155cc
Max Power : 13.5kW (18.4PS)/10000r/min
Maximum Torque : 14.2 NM @ 7,500 RPM
Bore : 58.0 mm
Stroke : 58.7 mm
Compression Ratio : 11.6:1
Fuel Delivery System : Fuel Injection
Clutch : Wet, Multiple Disc
BRAKES, WHEELS AND SUSPENSION
Front Brake Type : Disc Brake 282mm
Rear Brake Type : Disc Brake 220mm
Front Tyre Size : 100/80-17M/C 52P - Tubeless
Rear Tyre Size : 140/70R-17M/C 66H - Tubeless
Front Suspension : Telescopic upside down Front Fork
Rear Suspension : Swingarm (link suspension)
DIMENSIONS AND CHASSIS
Kerb Weight: 137Kg (with oil and full fuel tank)
Overall Length : 2005mm
Overall Width : 805mm
Overall Height : 1,080mm
Wheelbase : 1325 mm
Ground Clearance : 170mm (At Unladen {Kerb} Vehicle Weight) 120mm (At Laden* Vehicle Weight)
Seat Height : 810 mm
Chassis Type : Deltabox
OTHER INFORMATION
Fuel Tank Capacity : 10L
Speedometer : Digital
Fuel Gauge : Digital
Tachometer : Digital
Battery : 12V,4.0Ah(10HR)
Headlight Type : LED
Brake/Tail Light : LED
|
