Specifications |
ENGINE AND PERFORMANCE
Engine Type : Liquid Cooled, Single Cylinder, Dohc, 4 Valves
Bore X Stroke ( In Mm) : 84 mm X 81.5 mm
Displacement : 452cc
Compression ratio : 11.5:1
Max power : 40.02PS (29.44kW) @8000 rpm
Max torque : 40 Nm @ 5500 rpm
Idle RPM : 1300 rpm
Lubrication : Semi-Dry Sump
Engine Oil Grade : 10w40 Api Sn, Jaso Ma2, Semi Synthetic
Clutch : Wet Multiplate, Slip & Assist
Gear box : 6 Speed
Fuel Injection : Electronic Fuel Injection, 42mm Throttle Body, Ride By Wire System
CHASSIS AND DIMENSIONS
Type : Steel Twin Spar Frame, Using Engine As Stressed Member
Front Suspension : Telescopic Forks, 43 Mm
Front wheel travel : 140 mm
Rear Suspension : Linkage Type Mono-shock
Rear wheel travel : 150 mm
Wheel Base : 1440 mm
Ground Clearance : 169 mm
Length : 2090 mm
Width : 855 mm (Without Mirrors)
Height : 1095 mm (without mirrors)
Seat Height :780 mm
Dry weight : 174 kg
Kerb Weight (90% Fuel + Oil) : 185 kg
Payload with Standard Equipment :191 kg
Fuel tank capacity : 11 L
ELECTRICALS
Electrical System : 12V
Battery : 12 V, 8 AH
Head Lamp : LEAD Headlamp
Turn + Turn Signal Lamp : Integrated Turn & Tail Lamp, All Led
Other Equipment Cluster (Dash & Flash) : 4 Inch Round TFT Display With Phone Connectivity, Full Map Navigation (Powered By Google Maps), Media Controls
Cluster (Analogue)
Digi-analog instrument cluster (Tripper Pod Optional)
|
