Specifications |
ENGINE AND PERFORMANCE
Fuel System: EFI
Engine Type: 249 cc, single-cylinder inline, 4-stroke, liquid-cooled, SOHC
Bore × Stroke: 72 mm × 61.2 mm
Max Power: 18 kW / 8000 rpm
Max Torque: 22.5 Nm / 7000 rpm
Compression Ratio: 11.3:1
Clutch Type: Wet, multi-plate, manual clutch
Emission: EU5+
DIMENSIONS
Length × Width × Height: 2120 mm × 910 mm × 1225 mm
Wheelbase: 1415 mm
Rake: 26°
Trail: 102 mm
Steering: 42°
Grade Ability: 30°
Seat Height: 840 mm
Ground Clearance: 245 mm
Fuel Tank:13
Curb Weight: 154 kg
CHASSIS
Frame: Steel tube
Rear Fork: Double swingarm
Front Suspension: USD telescopic
Rear Suspension: Monoshock
Front/Rear Suspension Travel: 160 mm / 38 mm
Front Brake: Ø265 mm single disc, floating dual-piston caliper
Rear Brake: Ø220 mm single disc, single-piston caliper
Rim: Spoke wheel, WM1.85×21 | MT2.5×18
Front Tire: 80/100-21 M/C 51P
Rear Tire: 120/80-18 M/C 62P
ABS & CBS: ABS (250DUAL ABS only)
TCS: N/A
ELECTRONICS
Headlight: LED
DRL: LED
Taillight: LED
Turning Light: LED
Instrument: Digital
T-Box: N/A
Color Options: Tundra Grey, Lime Green, Polar White
|
