Specifications |
ENGINE & TRANSMISSION
Type : Liquid-cooled, single-cylinder, 4 valve, FI, DOHC
Capacity : 398.15 cc
Bore : 89 mm
Stroke : 64 mm
Compression : 12:1
Max Power EC : 40 PS / 39.5 bhp (29.4 kW) @ 8,000 rpm
Max Torque EC : 37.5 Nm @ 6,500 rpm
Exhaust : Stainless twin-skin header system with stainless steel silencer
Final Drive : X-ring Chain
Clutch : Wet, Multi-plate, Slip and Assist
Gear Box :6
CHASSIS
Frame : Hybrid spine and perimeter, tubular steel, bolt-on rear subframe
Swingarm : Twin-sided, cast aluminium
Front Wheel : Spoked Tubeless, 19 x 2.5 in
Rear Wheel : Spoked Tubeless, 17 x 3.5 in
Front Tyre : 100/90-19
Rear Tyre : 140/80-17
Front Suspension : 43 mm USD big piston forks, 150 mm wheel travel
Rear Suspension : Gas monoshock (RSU) with external reservoir and pre-load adjustment, 150 mm wheel travel
Front Brakes : Single, 320 mm fixed disc, 4-piston radial caliper, ABS
Rear Brakes : Single, 230 mm fixed disc, Brembo, single-piston floating caliper, ABS.
Instruments : Analogue speedometer, integrated multi-function LCD screen
DIMENSIONS AND WEIGHT
Width : 901mm
Height : 1169mm
Seat Height : 835 mm
Wheel Base : 1418 mm
Rake : 23.2 °
Trail : 108 mm
Wet Weight : 186 Kg
Full Capacity : 13 L
SERVICE
Service Interval : 8,000 KM / 6 months (whichever comes first)
|
