Specifications |
VARIANTS AND PRICES
TRAIL : Rs. 6,89,900
FORCE : Rs. 6,99,900
ENGINE AND TRANSMISSION
Engine Type : Single cylinder, 4 stroke, SOHC, air-cooled, fuel injection
Bore x Stroke ( in mm) : 81 x 86 mm
Displacement : 443 CC
Fuel injection : Electronic Fuel Injection
Compression ratio : 9.5:1
Idle RPM : 1300 rpm
Starting system : Electric Start
Maximum Torque : 34 Nm @ 4000 rpm
Clutch : Wet Multi Plates
Gear box : 6 Speed
Lubrication : Wet Sump
Maximum Power : 25.4 Bhp (18.7 KW) @ 6250 rpm
Engine Oil Grade : SEMI SYNTHETIC SAE 15W 50 API SL GRADE JASO MA 2
CHASSIS AND SUSPENSION
Type : HALF-DUPLEX SPLIT CRADLE FRAME
Front suspension : Telescopic, 41mm forks
Front Wheel Travel : 190 mm travel
Rear suspension :Monoshock with linkage
Rear Wheel Travel : 180 mm wheel travel
Wheelbase : 1460mm
Ground Clearance : 200mm
Seat Height : 795 mm
Length : 2165mm
Width : 840mm
Height : 1170mm (without mirrors)
Payload with Standard Equipment : 179 Kg
Fuel Capacity : 15 L
Dry Weight : 187 Kg (Alloy / Spoke)
Kerb Weight (90% Fuel + Oil) : 196 Kg (Alloy / Spoke)
BRAKES AND TYRES
Wheel Type : Spoke/Alloys
Tyre Type : Tube/ Tubeless
ABS : Dual Channel, Swichtable at rear
Tyres FR. :100/90 - 19” - dual-purpose tyres
Tyres RR. : 120/90 - 17” - dual purpose tyres
Brakes Front : Hydraulic Disc Brake 300mm disc, 2-piston floating caliper
Brakes Rear : Hydraulic Disc Brake240 mm disc, single piston floating caliper
ELECTRICALS
Electrical System : 12 V
Head Lamp : 14/12W LED
Tail Lamp : LED
Turn Signal Lamp : 12V, 10W
Other Equipment : USB Charger - Type A
Cluster : Digital - Analogue cluster
Navigation : Tripper Pod (Optional)
Battery : 12 V , 8 Ah Maintenance Free
|
