Specifications |
ENGINE AND PERFORMANCE
Engine Type: Liquid-cooled, 4-stroke, SOHC, 4-valve
Displacement :155 CC
Bore & Stroke : 58.0 mm × 58.7 mm
Compression Ratio: 11.6 : 1
Maximum horse power: 13.5kW(18.4PS)/10000r/min
E20 Compatible : Yes
Clutch Type : Wet, Multiple Disc
Transmission type : Constant mesh, 6-speed
Starting system type : Electric starter
Maximum torque: 14.1N.m(1.4kgf.m)/7500r/min
Fuel System: Fuel injection
DIMENSIONS
Overall length : 2015mm
Overall Width : 800mm
Overall Height : 1,070mm
Minimum ground clearance : 170 mm
Kerb Weight(with oil & a full fuel tank) : 141 kg
Seat height :810mm
Inner tube diameter of front fork : 37.0mm
Wheelbase :1,325 mm
Fuel tank capacity :10L
CHASSIS
Frame type : Deltabox
Front suspension system :Telescopic upside down Front Fork
Rear suspension system : Linked-Type Monocross Suspension
Brake type (Front) : Disc brake (282 mm)
Brake type (Rear) : Disc brake (220 mm)
Tyre size (front) :100/80-17M/C 52P - Tubeless
Tyre size (rear) : 140/70R-17M/C 66H - Radial Tubeless
ABS : Dual Channel
|
