Specifications |
ENGINE AND TRANSMISSION
Displacement: 155cc
Max Power : 12.3kW (16.7PS) / l0000r/min
Maximum Torque : 14.3 N.m (1.5 kgf.m) / 6500r/min
Bore : 58.0 × 58.7mm
Stroke : 4-Stroke
Compression Ratio : 11.6:1
Fuel Delivery System : Fuel Injection
Transmission Type : Constant Mesh, 6-Speed
Clutch : Wet, Multiple Disc
BRAKES, WHEELS AND SUSPENSION
Front Brake Type : Hydraulic Disc Brake
Rear Brake Type : Hydraulic Disc Brake
Front Tyre Size : 2.75 - 21 45P Tube Type
Rear Tyre Size : 4.10 - 18 59P Tube Type
Front Suspension : Telescopic Fork
Rear Suspension : Swing Arm (Link suspension) with Gas-charged Shock absorber
DIMENSIONS AND CHASSIS
Kerb Weight : 134 Kg
Overall Length : 2145 mm
Overall Width : 840 mm
Overall Height : 1200 mm
Wheelbase : 1430 mm
Ground Clearance : 245 mm
Seat Height : 880 mm
Chassis Type : Semi Double Cradle
OTHER INFORMATION
Fuel Tank Capacity : 8.1L
Speedometer : Fully Digital
Start Type : Electric Starter
Battery : 12V, 3.0AH / 3.0 AH l(10HR)
Headlight Type : 12V 35W / 35W × 1
Brake/Tail Light : 12V 18W / 5W × 1
|
