Specifications |
ENGINE AND TRANSMISSION
Type : Liquid-cooled, 4 valve, DOHC, single-cylinder
Capacity : 398.15 cc
Bore : 89
Stroke : 64
Compression : 0.500694444444444
Max Power EC : 39.5 HP (40PS) @ 8,000 RPM
Max Torque EC : 27.7 ft lb @ 6,500 rpm
System : Bosch electronic fuel injection with electronic throttle control
Exhaust : Stainless twin-skin header system with stainless steel silencer
Final Drive : X-ring chain
Clutch : Wet, multi-plate, slip
Gearbox : 6 speed
CHASSIS
Frame : Hybrid spine/perimeter, tubular steel, bolt-on rear subframe
Swingarm : Twin-sided, cast alloy aluminum
Front Wheel : Cast aluminum alloy 10 spoke, 19 x 2.5 in
Rear Wheel : Cast aluminum alloy 10 spoke, 17 x 3.5 in
Front Tire : 100/90-19
Rear Tire : 140/80-17
Front Suspension : 43mm upside down Big Piston forks. 150mm wheel travel
Rear Suspension : Gas monoshock RSU with external reservoir and pre-load adjustment. 150mm wheel travel
Front Brakes : 320mm fixed disc, four-piston radial caliper, ABS
Rear Brakes : 230mm fixed disc, ByBreTM single piston floating caliper, ABS
Instrument Display and Functions : Analogue speedometer with integrated multi-function LCD screen
DIMENSIONS AND WEIGHT
Width Handlebars : 35.47 in (901 mm)
Height Without Mirror : 46.02 in (1169mm)
Seat Height : 32.87 in (835 mm)
Wheelbase : 55.83 in (1418 mm)
Rake : 23.2 º
Trail : 4.25 in (108 mm)
Tank Capacity : 3.43 US gal (13 litres)
Wet Weight : 395 lb (179kg)
|
