| Details
|
|
Price |
Rs. 21,99,000
|
|
Type |
pickup |
|
Battery Size |
21.3 kwh
|
|
Fuel Type |
Electric |
|
Specifications |
VARIANTS AND PRICES
ACE EV Container : NPR 22,99,000
ACE EV CLB : NPR 22,79,000
ACE EV Flatbed : NPR 21,99,000
BATTERY AND RANGE
Battery Chemistry: LFP (Lithium Ion Iron Phosphate)
Battery Cooling System: Yes, Liquid cooling
Battery Energy capacity :21.3 kWh
Battery Pack nominal Voltage: 92.8 V
Certified range: 155 km
Steering System : Mechanical
Brakes : Hydraulic Brake
Brake - Front : Disc brakes
Brake - Rear : Drum brakes
Brake Drum Diameter : 228 mm
SUSPENSION
Parabolic leaf spring at front and semielliptical leaf spring at rear
Suspension - Front :Parabolic leaf spring
Suspension - Rear: Semi-elliptical leaf spring
Shock absorber : Hydraulic double acting telescopic type
Antiroll Bar :Provided at front.
TYRES
No of Tyres : 4, Front -2 Rear -2 Spare-1
No of Wheels: 4
Wheel Rims: 4.5JX13
Size & Ply rating: 155 R13 LT 8PR (TUBELESS TYRES)
Axle - Rear : Banjo Rear Axle
Axle Ratio - Rear : ~
Axle Final ratio: 4.44
DIMENSIONS AND CAPACITY
Ground Clearance: 160 mm
Overall Length: 3800 mm
Overall Width : 1500 mm
Overall Height (Unladen) : 2635 mm
Overall Height (Laden) : 2600 mm
Over Hang - Front : 980 mm
Over Hang - Rear : 720 mm
Turning Circle Radius: 4.3 m
Turning Circle Diameter: 8.6m
Turning Clearance Circle Diameter: 9.8m
Payload capacity: 600kg
Track Front : 1310 mm
Track Rear: 1343 mm
Length: 2211
Width: 1459
Height: 1475
GVW : 1840
Kerb Weight: 1240
Max Permissible: FAW 965
Max Permissible RAW : 875
Payload: 600
Cabin Ventilation: Non AC
Battery : 12 V , 55 Ah
Vehicle Drive : Automatic
Seats: 2
|
|
