Specifications |
Engine & Transmission
Displacement : 155cc
Maximum Torque : 14.1 Nm (1.4 kgfm) @8,500 RPM
Stroke : 58.7 mm
Compression Ratio : 11.6:1
Ignition : TCI (Transistor controlled ignition)
Transmission Type : Constant mesh, 6-speed
Max Power : 13.7kW(18.6PS)/10000 RPM
Bore : 58.0 mm
Valves Per Cylinder : 4-valve
Fuel Delivery System : Fuel Injection
No. of Gears : 6
Clutch : Wet, multiple disc
Brakes, Wheels & Suspension
Front Brake Type : Hydraulic single disc brake
Rear Brake Type : Hydraulic single disc brake
Front Tyre Size : 100/80-17M/C 52P - Tubeless
Tyre Type : Tubeless
Rear Suspension : Monocross Link suspension
Front Brake Size : 282 mm
Rear Brake Size : 220 mm
Rear Tyre Size : 140/70R17M/C 66H - Radial Tubeless
Front Suspension : Telescopic fork
Dimensions & Chassis
Kerb Weight : 142 kg
Ground Clearance : 170 mm
Chassis Type : Deltabox
Wheelbase : 1,325 mm
Seat Height : 815 mm
Other Information
Fuel Tank Capacity : 11 L
Speedometer : Digital
Start Type : Electric Start
Headlight Type : LED
Turn Signal : 12V, 10W×2
Reserve Fuel Capacity : 1.05 L
Fuel Guage : Digital
Battery : ETZ-5, 12 V, 4.0 Ah(10 HR)
Brake/Tail Light : LED
|
