Specifications |
ENGINE
Type: Single cylinder, 4-stroke, Air-Oil cooled
Displacement: 349cc
Bore x Stroke: 72 mm x 85.8 mm
Compression Ratio: 9.5 : 1
Maximum Torque: 27Nm @ 4000 rpm
Maximum Power: 20.2 BHP @ 6100 rpm (14.87 kW)
Ignition System: Electronic Fuel Injection (EFI)
Clutch: Wet, multi-plate
Gearbox: 5 Speed constant mesh
Lubrication: Wet sump, forced lubrication
Engine Oil: SAE 15 W 50 API, SL grade, JASo MA 2 Semi-synthetic
Air Cleaner: Paper element
Engine Start: Electric
CHASIS AND SUSPENSION
Type: Twin downtube spine frame
Front Suspension: Telescopic, 41 mm forks, 130 mm travel
Rear Suspension: Twin-tube emulsion shock absorbers with 6-step adjustable preload
BRAKES & TYRES
Front Tyre: 100/90 - 19 - 57P (Spoke)
Rear Tyre: 120/80 - 18 - 62P (Spoke)
Front Brake 300 mm disc, twin piston oating caliper
Rear Brake: 153 mm drum
ELECTRICALS
Electrical System: 12V - DC
Battery: 12V, 8 Ah, VRLA (Maintenance free)
Head Lamp: 12V, H 4 - 60/55w (Halogen)
Tail Lamp: 12V, P21/5W
Turn Signal Lamp 12V, 10W
DIMENSIONS
Wheelbase: 1390 mm
Ground Clearance: 170 mm
Length: 2145 mm
Width: 785 mm (Without mirrors)
Height: 1090 mm (Without mirrors)
Seat Height: 805 mm
Kerb Weight: 195 kg
Fuel Capacity: 13 l
|
