Specifications |
Operating weight : 11250 kg, 11350 kg, 12770 kg
Brand : JCB
Model : 116, 116DD, 116PD
Roller Type : Single Drum Roller
Drum width : 2100 mm
Engine Power : 100 hp
Amplitude Setting : 1.28/0.58 mm, 1.8/0.8 mm
Centrifugal Force : 256/147 kN
Max Travel Speed : 10.5 km/h, 11 km/h
Max Working Speed : 5 km/h, 6.5 km/h
Vibration Frequency : 32/36 Hz
Steering Angle : ±35°
Static Linear Load : 30.24 Kg/cm²
Tyre Size : 23.1 x 26 - 8 PR
No of Cylinders : 4
Max torque : 430 Nm
Rear Axle Load : 4900 kg
Front Axle Load : 6350 kg, 6450 kg, 7870 kg
Engine make : JCB
Turning Radius : 3.4 m
Engine Type : Water-Cooled, Four-Stroke, Turbo-Charged, After-Cooled Diesel Engine
Alternator output : 90 A
Battery : 12 V, 120 Ah
Steering System : Servo Assisted Centre Articulation with Automatic Oscillation
Drum Oscillation angle : ±15°
Hydraulic Tank Capacity : 80 L
Engine Coolant Capacity : 21 L
Wheel Base : 2846 mm
Side Overhang : 70 mm
Drum Diameter : 1500 mm
Diameter of Tyres : 1560 mm
Ground Clearance : 443 mm
Drum Shell Thickness : 28 mm
Overall machine length : 5473 mm
Overall machine width : 2240 mm
Engine Model : Diesel Max TCA-74, TCA-85
Fuel Tank Capacity : 300 L
Overall machine height : 2995 mm
With more compaction per pass, JCB brings the new 116 Soil Compactor that leads the industry in output and productivity. Equipped with an in-built compaction meter, this machine operates with precision, accuracy and speed. The compaction meter in the machine makes for uniform compaction every time which saves more time and fuel.
With the increasing demand in the building of roads throughout the country, the JCB 116 compactor is the machine that you need for your business.
|
