Specifications |
ENGINE
Displacement: 249 cc
Max net power: 12.5KW @ 7000 rpm
Max net torque: 18.5NM @ 5500 rpm
Brake horse power: 20 bhp
Engine Type: Single Cylinder, 4-stroke, 2-valve, Air Cooled Engine
Fuel System: Carburetor
Stroke: 65 mm
Bore: 70 mm
Compression ratio: 9:2:1
TRANSMISSION
No. of gears: 5
Gear pattern: 1-N-2-3-4-5
Gearbox
Clutch: Manual Wet Multi-Plate Clutch
Lubrication: Pressure Splash
Chain: 38t-520-Chain
DIMENSION AND WEIGHT
Length: 1980 mm
Width: 820 mm
Height: 1220 mm
Wheelbase: 1380 mm
Ground clearance: 240 mm
Dry weight: 115 kg
OTHER INFORMATION
Fuel tank capacity: 7.5 L
Starting method: Electric / Kick
TYRES
FRONT
Tyre size: 80 / 100
Brake type/size: 200mm disc
Rims/size: 19"
REAR:
Tyre size: 120 / 90
Brake type/size: 180mm disc
Rims/size: 16"
|
