| Details
|
|
Price |
Rs. 0
|
|
Engine Size |
0.0 cc
|
|
Fuel Type |
Diesel |
|
Specifications |
Engine
Net Power SAE 1349/ISO 9249- 35
Displacement: 2.2L
Gross Power-VR Engine-
SAE J1995: 38kW
Bore: 84mm
Stroke: 100mm
Engine Model- Cat®C2.2
METRI
Dimensions
Turning Radius from
Center-Machine Rear
- 1525 mm
Turning Radius from
Center–Coupler
-1195 mm
Turning Radius from
Center–Bucket
- 1944 mm
Maximum Reach w/Arms
Parallel to Ground
- 1291 mm
Rack Back Angle at
Maximum Height- 81
Wheel Base- 986 mm
Length w/o Bucket
- 2519 mm
Length w/Bucket on
Ground- 2519 mm
Height1- 950 mm
Maximum Overall Height
- 3709 mm
Bucket Pin Height at
Maximum Lift- 3709 mm
Bucket Pin Height at
Carry Position- 200 mm
Reach at Maximum Lift
and Dump- 505 mm
Clearance at Maximum
Lift and Dump- 2169 mm
Ground Clearance-195mm
Departure Angle- 26
Bumper Overhang Behind
rear Axle- 967 mm
Maximum Dump Angle: 40
Vehicle Width over
Tires1- 525 mm
Hydraulic System
HYDRAULIC FLOW –
STANDARD- 3,335 psi
Loader Hydraulic
Pressure- 23000 kPa
Loader Hydraulic Flow
- 61 L/min
Hydraulic Power
(calculated)- 23.2 kW
Service Refill Capacities
Chain Box,each side:6L
Engine Crankcase with
Filter- 10 L
Hydraulic System- 55 L
Hydraulic Tank- 35 L
Cooling System- 10 L
Fuel Tank- 58 L
|
|
