Specifications |
ENGINE
Displacement : 125 cc;
Maximum Torque : 9.7N.m(1.0kgf.m)/5000r/min;
Stroke : 4 Stroke;
Compression Ratio : 10.2:1;
Ignition : TCI (Transistor Controlled Ignition), Stop & Start System (SSS), Smart Motor Generator(SMG) System;
Transmission Type : V-belt automatic;
Max Power : 6.0kW(8.2PS)/6500r/min;
Bore : 52.4 mm;
Valves Per Cylinder : 2-valve;
Fuel Delivery System : Fuel injection;
Cooling System : Air Cooled;
DIMENSIONS AND WEIGHT
Kerb Weight : 99kg;
Overall Width : 685mm;
Wheelbase : 1,280mm;
Seat Height : 785mm;
Overall Length : 1,880mm;
Overall Height : 1,190mm;
Ground Clearance : 145mm;
BRAKES, WHEELS AND SUSPENSION
Front Brake Type: UBS
Rear Brake Type: UBS
Front Tyre Size: 90/90-12 Tubeless
Rear Tyre Size: 110/90-10 Tubeless
Front Suspension: Telescopic fork
Rear Suspension: Unit Swing
OTHER INFORMATION
Fuel Tank Capacity: 5.2L
Battery: Maintenance free - 12V,5.0 Ah
Headlight Type: 12V,35/35W x 1
Brake/Tail Light: 12V,21/5W x 1
|
