Specifications |
Engine
Type: Single Cylinder, 4-valve, DOHC, F.I. Engine
DISPLACEMENT : 373.27 cc
BORE x STROKE : 89 mm x 60 mm
POWER : 43.5 PS (32 kW) @ 9,000 rpm
MAX TORQUE : 37 Nm @ 7,000 rpm
FUEL INJECTION : Bosch Electronic Fuel Injection (EFI)
LUBRICATION : Wet Sump, Forced
COOLING SYSTEM : Liquid cooling with radiator
COMPRESSION RATIO : 12.88: 1
SUSPENSION
FRONT SUSPENSION : WP APEX USD open-cartridge forks, 43 mm diameter, 170mm travel
REAR SUSPENSION : WP APEX Monoshock, 177 mm wheel travel Adjustable for Preload (10 steps)
ELECTRONICS
INSTRUMENT CLUSTER TYPE : TFT Dash Display
RIDER AIDS : MTC, Riding Modes, Cornering ABS, Offroad ABS, Ride-by-wire, Quickshifter+,
STARTER / BATTERY
STARTER / BATTERY
CLUTCH
Slipper clutch, 12V USB socket
FRAME
FRAME : Split-Trellis Frame (Tubular)
SUBFRAME : Bolt on sub-frame
BRAKES
FRONT BRAKE : 320 mm Disc with Radially Mounted Caliper
REAR BRAKE : 230 mm Disc with Floating Caliper
FUEL TANK CAPACITY : 14.5 L (400+ kms tank range)
DIMENSIONS
GROUND CLEARANCE : 200 mm
SADDLE HEIGHT : 855 mm
KERB WEIGHT : 177 kg
|
