Specifications |
ENGINE TYPE: Single cylinder inline,4-stroke,Air cooled, Vertical
CAPACITY: 124.5 cc
BORE & STROKE: 57.0×8.8 mm(2.2×1.9in)
COMPRESSION RATIO: 9.0：1
FUEL SYSTEM: EFI
MAX. POWER OUTPUT: 7.0 kW/85000rpm
MAX. TORQUE: 8.3 N.m/6500 rpm
Maximum Speed 90 km/h
Ignition ECU
Transmission 6 speed
CHASSIS
FRONT SUSPENSION: Retractable
REAR SUSPENSION: Cantilever Type
BRAKES: Hydraulic
RIM: Front: 2.75×12 MT Light Aiioy/Rear: 3.50×12 MT Light Alloy
Tyre pressure Front: 120/70-12; Rear: 130/70-12
SIZE / WEIGHT
LENGTH x WIDTH x HEIGHT: 1724×750×995 mm(68x30x39in)
WHEELBASE: 1214 mm(48in)
SEAT HEIGHT: 775 mm(31.5in)
MIN. GROUND CLEARANCE: 145 mm(5.7in)
MIN. TURNING DIAMETER: 3.95 m(155in)
FUEL CAPACITY: 7L(1.9gal)
CURB WEIGHT: 114 kg(251lb)
MAX. PAYLOAD CAPACITY: 150kg(330lb)
|
