Specifications |
ENGINE TYPE: Single-cylinder,Liquid cooled,4-stroke,SOHC,4-Valve
CAPACITY: 495cc
BORE & STROKE: 91.0mm×76.2mm
COMPRESSION RATIO: 10.3:1
FUEL SYSTEM: Bosch EFI
MAX. POWER OUTPUT: 28 kW/6800 rpm (OFF-ROAD)
MAX. TORQUE: 43N•m/5800 rpm (OFF-ROAD)
IGNITION: ECU
TRANSMISSION: CVT
CHASSIS
SUSPENSIONS: Front/Rear: Double arm, independent suspension
DRIVE: Switchable 2WD/4WD
BRAKES: Front/Rear: Hydraulic
Shock Absorber: Front/Rear: Gas Spring, Spiral spring oil shock absorber
RIM: Front: 14 x 7.0 AT Aluminum Alloy/Radials 12 x 6.0 AT Aluminum Alloy/Radials
Rear: 14 x 8.0 AT Aluminum Alloy/Radials 12 x 7.5 AT Aluminum Alloy/Radials
TIRE: Front: 25 x 8.00-12; 26 x 9.00-12; 26 x 9.00-14
Rear: 25 x 10.00-12; 26 x 11.00-12; 26 x 11.00-14
SIZE / WEIGHT
LENGTH x WIDTH x HEIGHT: 2870 x 1510 x 1830mm
WHEELBASE: 2040mm
SEAT HEIGHT: 395mm
MIN. GROUND CLEARANCE: 287mm
MIN. TURNING DIAMETER: 5.4m
FUEL CAPACITY: 27L
CURB WEIGHT: 552kg
Minimum Turning Diameter: 9.5m
|
