Specifications |
ENGINE TYPE: 2-cylinder inline,4-stroke,Liquid cooled
CAPACITY: 649.3 cc
BORE & STROKE: 83×60 mm(3.3×2.4in)
COMPRESSION RATIO: 11.3:1
FUEL SYSTEM: Bosch EFI
MAX. POWER OUTPUT: 52.0 kW/8750rpm(71hp/8750rpm)
MAX. TORQUE: 62.0 N.m/7000 rpm
MAX. SPEED: 170 km/h
IGNITION: ECU
CHASSIS
FRONT SUSPENSION: Upside Down
REAR SUSPENSION: Cantilever Type
BRAKES: Hydraulic
FRONT TYRES/RIMS: 3.50×17 MT aluminium alloy
REAR TYRES/RIMS: 4.50×17 MT aluminium alloy
Tire Pressure Front: 120/70Z R17; Rear: 160/60Z R17
SIZE / WEIGHT
LENGTH x WIDTH x HEIGHT: 2150×835×1332 mm (85x33x52in)
WHEELBASE: 1415 mm (56in)
SEAT HEIGHT: 840 mm (33in)
MIN. GROUND CLEARANCE: 170 mm (7in)
MIN. TURNING DIAMETER: 5.4 m (213in)
FUEL CAPACITY: 18L (4.7gal)
CURB WEIGHT: 213 kg (468.6lb)
MAX. PAYLOAD CAPACITY: 150kg (330lb)
|
