Specifications |
ENGINE TYPE: 2-cylinder inline,8-valve, Liquid cooled,DOHC, Bosch EFI
CAPACITY: 400.4cc
BORE & STROKE: 68.4mm x 54.5mm
COMPRESSION RATIO: 11.1:1
FUEL SYSTEM: Bosch EFI
MAX. POWER OUTPUT: 31.5 kW / 9500 rpm（42hp)
MAX. TORQUE: 35.4 N.m / 7650 rpm
GEARBOX: 6-speed
CHASSIS
FRONT SUSPENSION: Telescopic fork
REAR SUSPENSION: Cantilever monoshock with adjustable rebound
BRAKES: Front: Twin Disc 300mm / Rear: Single Disc 220mm
BRAKES: (ABS model) Twin Disc 300mm / Rear: Single Disc 240mm, with Continental ABS System
FRONT TYRES/RIMS: 120/70ZR17 / 3.5x17MT rim CST
REAR TYRES/RIMS: 160/60ZR17 / 4.5x17MT rim CST
SIZE / WEIGHT
LENGTH x WIDTH x HEIGHT: 2114mm x 757mm x 1100mm
WHEELBASE: 1415mm
SEAT HEIGHT: 795mm
MIN. GROUND CLEARANCE: 150mm
MIN. TURNING DIAMETER: 5.4m
FUEL CAPACITY: 17L
WEIGHT: 193kg dry
MAX. PAYLOAD CAPACITY: 150kg
|
