Specifications |
ENGINE TYPE: Single cylinder, Liquid cooled EFI SOHC
CAPACITY: 149.4cc
BORE & STROKE: 57.0mm x 58.6mm
COMPRESSION RATIO: 10.5:1
FUEL SYSTEM: EFI
MAX. POWER OUTPUT: 10.7Kw/9000r/min
MAX. TORQUE: 12.2Nm/6800r/min
GEARBOX: 6-speed
CHASSIS
FRONT SUSPENSION: Upside down telescopic fork
REAR SUSPENSION: Mid positioned monoshock
BRAKES: Front: Single disc 292mm with twin-piston caliper / Rear: Single
disc 220mm with single piston caliper
FRONT TYRE/WHEEL: 100/80R17 CST Radial on 2.50 in. cast aluminium wheel
REAR TYRE/WHEEL: 130/70R17 CST Radial on 3.50 in. cast alumnium wheel
SIZE / WEIGHT
LENGTH x WIDTH x HEIGHT: 2025mm x 770mm x 1070mm
WHEELBASE: 1360mm
SEAT HEIGHT: 775mm
MIN. GROUND CLEARANCE: 150mm
MIN. TURNING DIAMETER: 5m
FUEL CAPACITY: 10L
WEIGHT: 135kg (dry)
MAX. PAYLOAD CAPACITY: 150kg
|
